Description
StarTech MINI PCI EXPRESS GIGABIT ETHERNET(ST1000SMPEX) (2 Years Manufacture Local Warranty In Singapore)
The ST1000SMPEX Mini PCI Express Gigabit Network Adapter Card adds 1000Mbps network connectivity to a Mini PCI Express (PCI Express Mini Card, Mini PCIe) enabled computer system, such as Mini-ITX motherboards.
Supporting features such as NDIS5 checksum and large send offload for lower CPU utilization, Wake-onLAN (WOL) and Remote Wake-up power management, jumbo frames and VLAN tagging, this Mini PCI Express Gigabit Adapter is ready to handle a wide variety of scenarios.
Perfect for small form factor or embedded systems that originally lack Gigabit networking capability, or for adding a network connection without taking up a full-sized PCI Express slots, this high quality Mini PCIe Network Adapter includes a low profile/half-height bracket for additional installation options.
Add a Gigabit RJ45 port through a Mini PCI Express slot
- One 10/100/1000Mbps compatible RJ-45 Ethernet port
- Fully complaint with IEEE 802.3, 802.3u, and 802.3ab specifications for 10/100/1000 Mbps connections
- Jumbo Frame support up to 9k
- Crossover Detection & Auto-Correction (Auto MDIX)
- IEEE 802.1Q VLAN Tagging support
- Supports Wake-on-LAN (WOL) and Remote Wake-up Support, Pair Swap/Polarity/Skew Correction
- Microsoft® NDIS5 Checksum Offload (IPv4, TCP, UDP) and Large Send Offload support
- Supports Full and Half duplex operating modes
- IEEE 802.3x Full Duplex Flow Control support
- Compliant with PCI Express Mini Card specification 1.1
- Includes Full and Low Profile installation brackets
Technical Specifications
| Media Type Supported | Twisted Pair |
| Network Technology | 10/100/1000Base-T |
| Additional Warranty Information | Free lifetime technical support. |
| Additional Information |
|
| System Requirements |
|
| Chipset Manufacturer | Realtek |
| Chipset Model | RTL8111E |
| Product Type | Gigabit Ethernet Card |
| Manufacturer Part Number | ST1000SMPEX |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | Mini PCI Express Gigabit Ethernet Network Adapter NIC Card |
| Brand Name | StarTech.com |
| Host Interface | Mini PCI Express |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Total Number of Ports | 1 |
| Thickness | 4.1 mm |
| Weight (Approximate) | 5.7 g |
| Form Factor | Plug-in Card |
| Height | 33 mm |
| Width | 144.8 mm |
| Depth | 50.8 mm |
| Card Height | Low-profile |
Resources
Quick Start Guide - st1000smpex.pdf
