HPE Data Cartridges

Is Tape is useful? The Value of Tape

Linear Tape-Open (LTO) is a magnetic tape data storage technology originally developed in the late 1990s as an open standards alternative to the proprietary magnetic tape formats that were available at the time. Hewlett Packard Enterprise, IBM, and Quantum control the LTO Consortium, which directs development and manages licensing and certification of media and mechanism manufacturers.

The standard form-factor of LTO technology goes by the name Ultrium, the original version of which was released in 2000 and stored 100 GB of data in a cartridge. The ninth generation of LTO Ultrium was announced in 2020 and can hold 18 TB in a cartridge of the same physical size.

Upon introduction, LTO Ultrium rapidly defined the super tape market segment and has consistently been the best-selling super tape format. LTO is widely used with small and large computer systems, especially for backup



HPE StoreEver Tape Solutions for SMBs – Tape Storage

This video explores HPE StoreEver tape solutions for SMBs, delivering cost-effective, fast, removable & easy-to-use storage. It provides ultimate air-gap protection to store data offline



Comparison Table for LTO1 to LTO9

LT01

LT02

LTO3

LTO4

LTO5

 LTO6

LTO7

LTO8

LTO9

Colour Blue  Maroon Yellow Green Light Blue Magenta Black Green ?
Release Date 2000 2003 2005 2007 2010 2012 2015 2017 2021
Native / Compressed 100Gb 200Gb 400Gb 800Gb 1.5Tb 2.5Tb 6Tb 12Tb 18Tb
Compressed 200Gb 400Gb 800Gb 1.6Tb 3Tb 6.25Tb 15Tb 30Tb 45Tb
Max Compressed Speed (MB/s) 40 80 160 240 280 400 750 900 1000
Encryption No No No Yes Yes Yes Yes Yes Yes
Compression Ratio 2:1 2:1 2:1 2:1 2:1 2.5:1 2.5:1 2.5:1 2.5:1



As HDD prices have dropped, disk has become cheaper relative to tape drives and cartridges. As of 2019, at any capacity, the cost of a new LTO tape drive plus one cartridge is much greater than that of a new HDD of the same or greater storage capacity. However, most new tape cartridges still have a lower price per gigabyte than HDDs, so that at very large subsystem capacities, the total price of tape-based subsystems can be lower than HDD based subsystems, particularly when the higher operating costs of HDDs are included in any calculation





Tape is also used as "offline" copy, which can be protection against ransomware that cipher, or delete data(e.g. tape is pulled out of the system in library, blocked from writing after making copy or using WORM technology). In 2019 about 80 percent of business (then modern) had data stored on tape
