StarTech USB C Multiport Adapter Mini Dock HDMI 4K or VGA 1080p Video - 100W Power Delivery Passthrough, 3-port USB 3.0 Hub, GbE, SD & MicroSD DKT30CHVSCPD - Buy Singapore

Roll over image to zoom in Click on image to zoom

StarTech USB C Multiport Adapter Mini Dock HDMI 4K or VGA 1080p Video - 100W Power Delivery Passthrough, 3-port USB 3.0 Hub, GbE, SD & MicroSD DKT30CHVSCPD (3 Years Manufacture Local Warranty In Singapore)

Name: StarTech USB C Multiport Adapter Mini Dock HDMI 4K or VGA 1080p Video - 100W Power Delivery Passthrough, 3-port USB 3.0 Hub, GbE, SD & MicroSD DKT30CHVSCPD (3 Years Manufacture Local Warranty In Singapore)
Brand: StarTech
SKU: DKT30CHVSCPD
Price: 150.00 SGD
Availability: OutOfStock

Save 30%

StarTechSKU: DKT30CHVSCPD

No reviews

Price:

$ 150.00 SGD $ 213.99 SGD

Quantity:

Share this product

StarTech USB C Multiport Adapter - USB Type-C Mini Dock with HDMI 4K or VGA 1080p Video - 100W Power Delivery Passthrough, 3-port USB 3.0 Hub, GbE, SD & MicroSD - Laptop Travel Dock DKT30CHVSCPD (3 Years Manufacture Local Warranty In Singapore)

Add video output, three USB 3.0 ports, SD/micro SD card readers, and GbE port to your laptop through a single USB-C port

8-IN-1 USB-C PORTABLE MINI DOCK: Eliminates the hassle of carrying multiple adapters w/ 4K 30Hz HDMI or 1080p VGA video, 3x 5Gbps USB-A, SD slot, microSD slot, 1x Gigabit Ethernet, 1x headset/mic jack
POWER FLEXIBILITY: Travel dock is USB bus powered and supports up to 100W Power Delivery 3.0 Passthrough; 15W reserved for dock and up to 85W for laptop charging using your USB-C power adapter
SIMULTANEOUS SD & MICRO SD ACCESS: USB-C multiport adapter provides both a SD/SDHC/SDXC and a MicroSD card reader for additional data storage or backup, and provides access to both simultaneously
8-IN-1 USB-C PORTABLE MINI DOCK: Eliminates the hassle of carrying multiple adapters w/ 4K 30Hz HDMI or 1080p VGA video, 3x 5Gbps USB-A, SD slot, microSD slot, 1x Gigabit Ethernet, 1x headset/mic jack
POWER FLEXIBILITY: Travel dock is USB bus powered and supports up to 100W Power Delivery 3.0 Passthrough; 15W reserved for dock and up to 85W for laptop charging using your USB-C power adapter
SIMULTANEOUS SD & MICRO SD ACCESS: USB-C multiport adapter provides both a SD/SDHC/SDXC and a MicroSD card reader for additional data storage or backup, and provides access to both simultaneously

Turn your USB-C™ equipped laptop into a mobile workstation. This sleek, compact USB-C multiport adapter makes it easy to connect your MacBook Pro or Windows laptop to an HDMI or VGA monitor. Power through your workday, with three USB 3.0 (Type-A) ports with Fast-Charge support, SD™ and microSD™ card slots, and a Gigabit Ethernet port.

Connect to an external monitor

The universal USB Type-C™ multiport adapter (Thunderbolt 3 port compatible) offers enhanced productivity in the boardroom or classroom. Connect your laptop to one external monitor:

4K HDMI (3840 x 2160p @ 30Hz) or VGA (1920 x 1200 @ 60Hz)

Charge your laptop and peripherals

With support for USB Power Delivery 3.0 (up to 85W), the USB-C multiport adapter lets you power and charge your laptop, and power your peripherals at the same time. PD 3.0 features Fast Role Swap to prevent USB data disruption when switching power sources (bus power and USB-C power adapter).

Connect USB devices

Connect your USB devices using the three USB 3.0 (Type-A) ports. Each USB port is a fast-charge and sync port, to ensure your tablet and smartphone are charged and ready. Each port offers 7.5W of charging power, with a combined total of 10W with all three ports in use.

SD/microSD card access

Access the SD and microSD slots at the same time, and easily move data from one card to the other.

Easy portability

For mobile use, the USB-C adapter is bus-powered and lightweight, with a wraparound USB-C cable.

DKT30CHVSCPD is backed by a StarTech.com 3-year warranty and free lifetime technical support.

Applications

Create a mobile workstation, connected to an HDMI or VGA monitor
Give presentations by connecting to an HDMI monitor in the boardroom or classroom
Connect to Gigabit internet where Wi-Fi® isn't available
Ideal for working with SD and microSD flash media used in cameras and smartphones
Compact size with essential ports for smaller or temporary workspaces

Specifications

Warranty Information	Warranty	3 Years
Connector(s)	Connector Type(s)	1 - HDMI (19 pin)
		1 - VGA (15 pin, High Density D-Sub)
		3 - USB 3.0 A (Fast-Charge, 9 pin)
		1 - RJ-45
		1 - SD / MMC Slot
		1 - MicroSD
		1 - USB-C (24 pin) USB Power Delivery only
		1 - USB Type-C (24 pin) USB 3.0 (5Gbps)
Environmental	Operating Temperature	0°C to 45°C (32°F to 113°F)
	Storage Temperature	-10°C to 70°C (14°F to 158°F)
	Humidity	10%-85%RH
Hardware	4K Support	Yes
	Fast-Charge Port(s)	Yes
	Displays Supported	1
	Bus Type	USB-C
	Industry Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab USB 3.0 - Backward compatible with USB 2.0 and 1.1
	Chipset ID	VIA/VLI - VL102 VIA/VLI - VL817 Parade - PS8338B Parade - PS176 Analogix - ANX9833 ALCOR MICRO - AU84612 Realtek - RTL8153
Packaging Information	Shipping (Package) Weight	0.3 lb [0.1 kg]
	Package Length	5.6 in [14.2 cm]
	Package Width	6.7 in [17 cm]
	Package Height	1.2 in [30 mm]
Performance	Maximum Data Transfer Rate	5 Gbps (USB 3.0) 2 Gbps (Ethernet; Full-Duplex)
	Maximum Analog Resolutions	1920 x 1200p @ 60Hz (VGA)
	Maximum Digital Resolutions	3840 x 2160p (HDMI) @ 30Hz Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p
	Audio Specifications	The HDMI port supports audio output
	Type and Rate	USB 3.0 - 5 Gbit/s
	UASP Support	Yes
	Compatible Networks	10/100/1000 Mbps
	Auto MDIX	Yes
	Full Duplex Support	Yes
	General Specifications	With support for USB Power Delivery 3.0, the multiport adapter will power and charge your laptop, and power your peripherals at the same time, providing up to 85W of charging power, when using a 100W power adapter. Charging power will be less when using a lower-wattage power adapter.
		Supports Fast Role Swap of PD 3.0, to ensure the connected devices will not be disconnected when your power adapter is disconnected from the multiport adapter.
		Each USB 3.0 port provides up to 7.5W of charging power, with a combined total of 10W when all 3 ports are in use. The charge provided depends on the number of devices connected and the amount of current each device draws.
		Each one of the three USB 3.0 (Type A) ports is also a fast-charge and sync port to charge your tablet or smartphone. Only one fast-charge port can be used at a time.
Physical Characteristics	Color	Black
	Material	Plastic
	Cable Length	4.6 in [118 mm]
	Product Length	4.8 in [12.2 cm]
	Product Width	2.8 in [70 mm]
	Product Height	0.6 in [1.4 cm]
	Weight of Product	4.6 oz [129 g]
Power	Power Source	USB-Powered
Software	OS Compatibility	Windows® 7, 8, 8.1, 10 Mac OS® 10.11 to 10.15 Chrome OS™
Special Notes / Requirements	System and Cable Requirements	A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 3.0 and DP Alt Mode)
		USB-C power adapter (for example, your laptop’s USB-C based power adapter)
	Note	Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 3.0 and DP Alt Mode.
		The adapter can connect to a host laptop’s USB-C port that doesn’t support USB Power Delivery 3.0. However, if your laptop’s USB-C port supports USB Power Delivery 2.0, it will still support PD pass-through, but it will not support Fast Role Swap. If you laptop's USB-C port does not support Power Delivery, then it will not support PD pass-through.
		A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K)
		USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.
		Your laptop might have specific charging requirements. The USB-C adapter supports USB Power Delivery 3.0 to provide up to 85W of charging power, when using a 100W power adapter. Charging power will be less when using a lower-wattage power adapter.
What's in the Box	Included in Package	1 - multiport adapter
		1 - User manual
