Description
Ubiquiti UniFi Dream Machine UDM-US
(Warranty in Singapore)
All-in-one enterprise security gateway & network appliance for small to medium-sized businesses. The optimal experience for larger networks.
- All-in-one 1U rack appliance for small to medium sized businesses
- Combines new UniFi OS with 8-port switch and security gateway
- UniFi Protect video surveillance NVR with off-the-shelf 3.5" HDD support
- 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN
- Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities
- Powered by fast 1.7 GHz quad-core processor
UniFi Dream Machine Pro (UDM-Pro) is an all-in-one enterprise network appliance. UDM-Pro integrates all current and upcoming UniFi controllers with a security gateway, 10G SFP+ WAN, 8-port Gbps switch and off-the-shelf 3.5" HDD support.
How to install video
The Best Experience for Large Networks
All-in-one 1U rack appliance for small to medium size businesses
✔ Security Gateway
The enterprise-class security gateway combines routing, 10 Gbps SFP+ WAN, application visibility, VPN services, and 3.5 Gbps full threat management throughput into a single device.
|
10 Gbps
SFP+ WAN |
Advanced
Firewall with VPN |
DPI: Deep
Packet Inspection |
IPS/IDS - Intrusion
Prevention System |
3.5 Gbps IDS/IPS
Throughput |
UniFi Cloud Portal
Launch all current and upcoming controllers from a single view with simple access.
Safe Access with SSO
Single Sign-On (SSO) authentication streamlines safe access to UniFi applications.
Centralized User and Access Management
Admins easily manage users in one central location.
Installation of New Applications
Install new UniFi apps and maintain them with a single click through the settings page.
Seamless Network Integration
Use the UniFi Dream Machine Pro as your network controller.
Product Specifications:
DIMENSIONS
- Width x Height x Depth:
442.4 x 43.7 x 285.6 mm
(17.42 x 1.72 x 11.24") - Weight: 3.90 kg (8.60 lb)
- With Mounting Kits:
3.99 kg (8.80 lb)
PACKAGE CONTENTS
- (2) Rackmount Brackets
- (8) Bracket Screws
- (4) Mounting Screws
- (4) Cage Nuts
- (1) Security Screw
- (4) 2.5" HDD Screws
- Power Cord
- (4) Rubber Feet
TECHNICAL SPECIFICATIONS
Interfaces
- (8) 10/100/1000 RJ45 LAN Ports
- (1) 10/100/1000 RJ45 WAN Port
- (1) 1/10G SFP+ LAN Port
- (1) 1/10G SFP+ WAN Port
Management Interfaces
- Ethernet In-Band
- (1) Bluetooth BLE
Technical Information
- IDS/IPS Throughput: 3.5 Gbps *
- Processor: Quad ARM Cortex-A57 Core at 1.7 GHz
- System Memory: 4 GB DDR4
- On-Board Flash Storage: 16 GB eMMC
- * Measured with iPerf3.
Environment
- Operating Temperature: -10° to 40° C (14° to 104° F)
- Operating Humidity: 5 to 95% Noncondensing
Power
- Max. Power Consumption: 33W
- Voltage Range: 100 to 240VAC
- Power Method: (1) Universal AC Input, 100-240VAC, 50/60 Hz
- Redundant Power: (1) RPS DC Input
- Power Supply: Internal 50W/12V
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
Certifications
- CE, FCC, IC
