Ubiquiti Wireless Access Point WiFi 7 Unifi U7-Pro Wall (2 Years Hardware Warranty)-Promo Price While Stock Last

UbiquitiSKU: U7-Pro-Wall
No reviews

Price:
Sale price$ 285.00 SGD

Description

Ubiquiti Wireless Access Point WiFi 7 Unifi U7-Pro Wall (2 Years Hardware Warranty)-Promo Price While Stock Last

Wall-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support tailored for home builders with seamless installation options.

Specification

Overview

Dimensions
150 x 103 x 36 mm (5.9 x 4.1 x 1.4")

WiFi Standard
WiFi 7

Spatial Streams
6

Coverage Area
140 m² (1,500 ft²)

Max. Client Count
300+

Uplink
2.5 GbE

Mounting
Wall (Mount Included)

Power Method
PoE+

Performance

MIMO
6 GHz
2 x 2 (DL/UL MU-MIMO)
5 GHz
2 x 2 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)

Max. Data Rate
6 GHz
5.8 Gbps (BW320)
5 GHz
4.3 Gbps (BW240)
2.4 GHz
688 Mbps (BW40)

Antenna Gain
6 GHz
6 dBi
5 GHz
5 dBi
2.4 GHz
4 dBi

Max. TX Power
6 GHz
23 dBm
5 GHz
26 dBm
2.4 GHz
22 dBm

Max. BSSIDs
8 per Radio

Supported Data Rates
802.11be (WiFi 7)
7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
802.11ax (WiFi 6/6E)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Features

Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)

Captive Hotspot Portal
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN

Hardware

Max. Power Consumption
22W

Supported Voltage Range
44—57V DC

Networking Interface
(1) 1/2.5 GbE RJ45 port

Weight
580 g (1.3 lb)

Management
Ethernet

Enclosure Material
Polycarbonate, aluminum

Mount Material
Aluminum

LEDs
System
White/Blue

Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)

NDAA Compliant

Certifications
CE, FCC, IC, Anatel

Operating Frequency
US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8 : 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz 5925 - 7125 MHz

Ambient Operating Temperature
-30 to 60° C (-22 to 140° F)

Ambient Operating Humidity
5 to 95% noncondensing

Software

Application Requirements
UniFi Network
Version 8.1.113 and later

In The Box
