EATON 5P 650i Rack UPS 9210-3361

EatonSKU: 9210-3361
No reviews
American Express Apple Pay Google Pay GrabPay Mastercard PayNow PayPal Visa

Price:
Sale price$ 420.00 SGD

Description

EATON 5P 650i UPS 9210-3361

Eaton 5P, 650i Rack1U, 650 VA, 420 W, Input: C14, Outputs: (4) C13, Rack, 1U

The new Eaton 5P is the next generation 650VA-1550VA line-Interactive UPS with advanced LCD and energy metering feature. 5P is the perfect UPS to protect IT & networking devices such as servers, switches, routers and storage devices, in tower or rack format.

5P features and benefits

Eaton 5P is an energy-efficient line-interactive UPS with advanced LCD and energy metering features.

Manageability
• The new graphical LCD display provides clear information on the UPS’s status and measurements on a single screen (in seven languages). Enhanced configuration capabilities are also available with easy-to-use navigation keys.
• The 5P can meter energy consumption providing kWh values through the LCD and Eaton’s power management software.
• Load segment control enables prioritised shutdowns of non-essential equipment during outages in order to maximise battery runtime for critical devices. Load segment control can also be used to remotely reboot locked-up network equipment or to manage scheduled shutdowns and sequential start-ups.
• The 5P offers Serial and USB connectivity, plus an extra slot for an optional communication card (including SNMP/ Web card or relay contact card). Eaton’s Intelligent Power Software Suite compatible with all major OS including virtualisation software such as VMware and Hyper-V is included with each UPS.

Performance and efficiency
• Energy efficient UPS: With an optimised electrical design, the 5P provides up to 98% efficiency, reducing cooling and utility costs.
• Pure sinewave output: When operating in battery mode the 5P provides a high-quality output signal for any sensitive equipment connected, such as active PFC (power factor corrected) servers.
• Adjustable tolerance and sensitivity: Users can maximise useful battery life by widening the input voltage window or adjustable input waveform sensitivity (via the LCD or software) to adapt the UPS to a specific environment (like Genset).

Availability and Flexibility
• The 5P is available in tower or Rack 1U format, providing unmatched energy density with up to 1.1 kW in only 1U.
• Stronger, longer battery life: Eaton ABM® battery management technology uses an innovative three-stage charging technique that extends batteries by up to 50%.
• Batteries can be hot-swapped without ever having to shut down connected equipment. With an optional, hot-swap maintenance bypass module, you can even replace the entire UPS.

Three-year warranty

The 5P warranty covers both the UPS for three years.
Batteries for two years.

Technical Specifications

Basic
Application/Usage: Network Device
Router
Server
Storage Device
Switch
Telecommunication
Computer System
IT System
Mission Critical Equipment
Product Type: Line-interactive UPS
Input Voltage: 230 V AC
Form Factor: Tower
Waveform Type: Pure Sine Wave
Receptacles: 4 x IEC 60320 C13 (10A)
Brand Name: Eaton
Plug/Connector Type: IEC 60320 C14
Input Voltage Range: 160 V AC - 294 V AC
Product Family: 5P
Backup/Run Time (Half Load): 9 Minute
Backup/Run Time (Full Load): 2 Minute
Load Capacity (VA): 650 VA
Load Capacity (Watt): 420 W
Battery Information
Battery Chemistry: Lithium Ion (Li-Ion)
Number of Batteries: 1
Backup/Run Time (Half Load): 9 Minute
Backup/Run Time (Full Load): 2 Minute
Environmental Conditions
Maximum Operating Temperature: 35°C
General Information
Product Type: Line-interactive UPS
Manufacturer Part Number: 9210-3361
Manufacturer Website Address: http://www.eaton.com
Packaged Quantity: 1
Manufacturer: Eaton Corporation
Product Model: 5P650i
Product Name: 5P650i 650VA Tower UPS
Product Series: 5P
Brand Name: Eaton
Interfaces/Ports
Serial Port: Yes
USB (HID Compliant) Port: Yes
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS
Physical Characteristics
Weight (Approximate): 7.80 kg
Form Factor: Tower
Height: 230 mm
Width: 150 mm
Depth: 345 mm
Power Description
Input Voltage: 230 V AC
Output Voltage: 240 V AC
208 V AC
200 V AC
230 V AC
220 V AC
Load Capacity: 650 VA/420 W
Waveform Type: Pure Sine Wave
Input Voltage Range: 160 V AC - 294 V AC
Output Frequency: 50 Hz to 60 Hz
Input Frequency: 47 Hz to 70 Hz
Technical Information
Application/Usage: Telecommunication
IT System
Computer System
Mission Critical Equipment
Network Device
Router
Switch
Storage Device
Server
Receptacles: 4 x IEC 60320 C13 (10A)
Plug/Connector Type: IEC 60320 C14
AVR: Yes
Warranty
Limited Warranty: 3 Year


RESOURCES

Eaton 5p Datasheet

Eaton 5px ups brochure

Eaton 5px ups quick start guide

Eaton 5px ups 230v manual
