Logitech Tap Scheduling Touch Screen - Graphite 952-000091 (2 Years Manufacture Local Warranty In Singapore)

RIGHT PLACE, RIGHT TIME

Tap Scheduler makes it easy to see meeting details and reserve a room for ad hoc or future meetings. Easily deploy as a purpose-built scheduling panel for leading room scheduling solutions to help workers find and claim the right space.

GREEN MEANS GO

Quickly find an open room through colored LED lights that show availability at a distance.

CLEAN AND EASY INSTALL

Included mounts and clean cabling help ensure a tidy and professional setup.

Specification

• DIMENSIONS

  Device-only

  • Height: 165 mm
  • Width: 246.2 mm
  • Depth: 28.5 mm
  • Weight: 0.7 kg

  Surface-mounted

  • Height: 165 mm
  • Width: 246.2 mm
  • Depth: 31.4 mm

  Mullion-mounted

  • Height: 165 mm
  • Width: 292.6 mm
  • Depth: 44.5 mm

• TECHNICAL SPECIFICATIONS

  Screen

  • Size: 10.1” diagonal
  • IPS (In-Plane Switching)
  • LCD Panel with LED Backlighting
  • Resolution: 1280 x 800 resolution
  • Touch: Capacitive, 10 points multi-touch
  • Brightness: 400 nits
  • Contrast: 1000:1
  • Anti Fingerprint: Oleophobic coating
  • Viewing angle: 85 degrees (U/D/L/R)
  • Position angle: 0 degrees (flat on mounting surface)

  General Specifications

  • Integrated accelerometer
  • Integrated ambient light sensor
  • 100 mm x 100 mm VESA FDMI
  • Cable exits: horizontal / vertical / center

  COMPATIBILITY AND CERTIFICATIONS

  • Logitech Tap Scheduler integrates with leading room scheduling solutions as a
    • Microsoft Teams Panel
    • Zoom Rooms Scheduling Display
    • Robin-Powered scheduling panel
    • Appspace
    • RICOH Spaces
    • Meetio scheduling panel
  • See www.logitech.com/support/tapscheduler-compatibility for the latest certification and compatibility information.
  • Logitech CollabOS platform
  • Logitech Sync Remote Management

  Power and Cables

  • Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device.
  • *Requires PoE enabled network or PoE Injector and ethernet cable (Not included)

  PORTS AND INTERFACES

  • Ethernet: 10/100 Mbps
  • WiFi: 802.11a/b/g/n/ac
  • Bluetooth 5.0 (inactive, reserved for future use)

  Environmental

  • Operating Temperature: 0 to 40°C
  • Storage Temperature: -40 to 70°C
  • Humidity: 10-95%

  Security

  • Full Disk Encryption: AES-128
  • Data Encryption: Symmetric Keys, PKI
  • Device Identity: Protected by device attestation
  • Key Protection: Arm TrustZone

• PACKAGE CONTENTS

  • Logitech Tap Scheduler
  • Multi-surface mount (glass/drywall)
  • Corner mount accessory
  • Mullion mount
  • Mounting hardware
  • Documentation

• WARRANTY INFORMATION

  Ensure peace of mind with an extended warranty for Tap Scheduler, adding one additional year to the standard two-year limited hardware warranty.
  Contact your reseller for availability.

• PART NUMBER

  • Graphite : 952-000091
