Description
Logitech Reach with Base Mount (960-001670)
The Logitech Reach is an adjustable overhead content camera designed for document and desktop presentation. It captures video at up to 1080p at 60 frames per second using a glass lens. The unit connects via USB-C for simple operation with standard computers.
Specifications
| Part number | 960-001670 |
|---|---|
| Model | Reach |
| Brand | Logitech |
| Desktop Surface View Area @max zoom out | 11.81 x 21.65in (30x 55 cm) |
| Desktop Surface View Area @max zoom in | 2.76 x 5.12in (7x 13 cm) |
| Magnification/Zoom | 4.3X lossless |
| Independent Lateral Adjustment | single handed with 12.72 in (32.3 cm) of horizontal travel and 360º panning rotation |
| Independent Vertical Adjustment | Multipoint push button to engage 12.20 in (31 cm) of vertical travel |
| Camera Head Adjustment | 360º rotation on camera ring interface, 180º tilt and 360º rotation on ball joint interface |
| Max Video Resolution | 1080p/60 fps in MJPEG |
| Lens | Premium Full HD, Glass lens, f/2.0 - focal length 0.15 in (3.7 mm) and 78° DFOV |
| Audio Capture | Dual omnidirectional mic with noise reduction filter |
| USB-C Cable with 3 feet (91.5 cm) of length available | Extension cables can be used to provide additional range but may impact max video quality |
| Dimensions above surface in compact mode | Height 23.2 in (59 cm), Width 7.48 in (19 cm), Depth 7.48 in (19 cm) |
| Dimensions above surface in desktop mode | Height 20.87 in (53 cm), Width 21.65 in (55 cm), Depth 7.48 in (19 cm) |
| Weight | 4.05 kg |
| Surface texture | Non marring, grip layer on bottom of base |
| Logitech Reach with Clamp mount Dimensions above surface in compact mode | Height 23.2 in (59 cm), Width 3.94 in (10 cm), Depth 3.94 in (10 cm) |
| Logitech Reach with Clamp mount Dimensions above surface in desktop mode | Height 20.87 in (53 cm), Width 21.65 in (55 cm), Depth 3.94 in (10 cm) |
| Max Edge thickness | 2.20 in (5.6 cm) |
| Recommended under table clearance for clamping | 2.13 in (5.4 cm) |
| Logitech Reach with Clamp mount Weight | 3.3 lbs (1.5 kg) |
| Logitech Reach with Clamp mount Surface texture | Non marring, grip layer on both clamping surfaces |
Frequently asked questions
How does the Logitech Reach connect to computers?
The unit offers plug and play functionality via a USB-C interface. It is compatible with most computers and conferencing platforms.
How does the zoom feature operate?
Pressing an analog button activates a 4.3x lossless zoom with automatic focus.
What warranty does it come with?
2-year manufacturer warranty in Singapore.
Are prices inclusive of GST?
No. All prices are shown exclusive of GST.
